White's hipmount coinmaster 4000d serie2

[la Taupe]

acquired this old boy at a garage clearance and it came whithout coil and rod .
as connectors ( 5 pins ) are the same I plugged a CM 2000D serie 3 coil and
it works .
as far as I know there is a " set/reset " push switch on hipmount handle .

on witch pin connect it ???

thanks for help

[Carl-NC]

Here's the schematic for the 4000d Series 2.

CM4000Ds2.pdf

[la Taupe]

great Mr Carl !! thank you .
tomorrow I'll check if I find wires of same colors on plug and make some testings .

[Melbeta]

Here's the schematic for the 4000d Series 2.

[ATTACH]57455[/ATTACH]

Carl, that is fantastic service. I never been on a forum before like your forum. I really really like it.
MELBETA

[Melbeta]

Here's the schematic for the 4000d Series 2.

[ATTACH]57455[/ATTACH]

Carl, I just checked, I do not have that particular 4000d Series 2 schematic, and since it is a .pdf file, I cannot open it with this computer, so can you email it to me, there I can download it into my Whites Schematics files.
Melbeta
