Magnum on steroids!

[nikko10]

https://webmail.meta.ua/download.php....Sent&ent_id=2
This is the best PCB

[bandito]

https://webmail.meta.ua/download.php....Sent&ent_id=2
This is the best PCB

Upload here

[nikko10]

go to the link published above, download the RAR archive, open and there everything. What's the problem, I do not understand

[Hyena]

Nikko10 GM4

Attached

[nikko10]

Спасибо за помощь Hyena,там есть еще файл лицевой панели

[bandito]

Congratulations. You've already stopped selling PCBs

[nikko10]

Thank you for your congratulations, but you are wrong. There are a lot of devices on our, Russian-language sites, such as "Kvazar ARM", "Fortuna M, M2", "Terminator", "Megatron M", "Clone PI AVR" are freely available , i.e., all documentation is available-from the circuit to the printed circuit board. However, few people are able to assemble, set up, properly shape the appearance. So buyers for my age will suffice, it would be health (two months ago I had a heart attack). I applied personally and received an offer to buy, so I broke the monopoly. Let the radio amateurs collect the device. E e Thank you again for your attention!

[Hyena]

CDR

I was not able to attach CDR files (can not zip under 1MB), so I saved it in https://files.fm/u/736c3t63

[bandito]

He is ready if someone treats him, let him write

[nikko10]

I do not know what the word "treats" implies, but the board works without any problems, it was tested in assembly and on the ground on a real cop. Use, dear colleagues, radio amateurs !!!

translator incorrectly translated-verified in real search

[bandito]

If someone needs it. Error in translation

[nikko10]

Of course you need !!! I will also ask you to lay out this board, it works very well! Colleague, radio amateur, do not be nervous, let others gather MAGNUM

[nikko10]

Good evening! Dear amateurs, who can give a scheme for this board (the board was previously published in the subject, brought to a normal state)? The board works very well, but we need a scheme

[Nexus]

I do not know what the word "treats" implies, but the board works without any problems, it was tested in assembly and on the ground on a real cop. Use, dear colleagues, radio amateurs !!!

translator incorrectly translated-verified in real search

The value of all components is printed on the board, so you would not need a schematic. However if you do need a schematic can trace it back with ease. It's only a two layer board.

[nikko10]

Thanks for the answer. You can track the board, but the scheme is easier and it takes less time
