  • Originally posted by Dennis the Mennis View Post
    Hi Simon ,

    These are my settings for the DISC sync pulse vs Tx :

    Yes , I was confused while posting the DISC vs Rx , I've had in mind that the Rx was sampled , but as I understand that is not for sure (?) .

    DISC potmeter 0% :

    [ATTACH]15260[/ATTACH]

    and

    [ATTACH]15261[/ATTACH]

    DISC potmeter at 50% :

    [ATTACH]15262[/ATTACH]

    and

    [ATTACH]15263[/ATTACH]

    DISC potmeter at 100% :

    [ATTACH]15264[/ATTACH]

    and

    [ATTACH]15266[/ATTACH]

    Also here a little spike as described in previous post : most likely cause C9 ( in my case anyway) .

    It seems that the shift of Habitbrakers pcb is a little more shifted to the right and if it works for him I'll have to 'tune' my Rx a little so I can get some discrimination .




    video DISC sync pulse vs Tx : http://youtu.be/opZh96JHWFc?hd=1




    video DISC potmeterwiper vs Tx : http://youtu.be/0-JAuOxsQdg?hd=1


    kind regards ,

    Dennis the Mennis


    ps

    Simon ,

    You could have been right during the ' Blob test ' ... most likely I've forgot my 24 carat Golden Rolex .

    Another Blobtest ?
    Hi DtM!

    Love those great graphs you get with your USB scope! I have a configuration question: can you configure the graphs to have 10 dots per square instead of 12 (for easy estimate of values)? And can you configure it to show the time scale on the horizontal axis? It would be great also if description of plot can be put on graph so it can be understood without surrounding text. Just some ideas. I hope to get a similar tool some day.

    Ok, now lets look at your data.

    1. I think your sync pulse looks pretty normal and you should be able to discriminate targets. When I compare these new graphs to habitbraker, they quite similar in shift and location, don't you think so?

    So my question is: what targets do you use for your discrimination test, and what results do you get again? (My best test target is US Nickel. TGS does not discriminate silver or even copper really).

    2. I have seen a similar "spike" on my RX null signal at times. I did not consider it might be due to capacitor C9, but that could make sense due to saturation of the LF353 op amp. (The good news, as you said, is that the spike does not seem to hurt the detection. Anything very periodic at the TX frequency should not hurt.)

    However, the "spikes" on the sync pulse can be definitely related to capacitor C9, because when the LF353 op amp saturates (DISC op amp, pins 1,2,3), it causes a "ringing" output at pin 1 which then can make a messy sync pulse. (Surprisingly, the messy sync pulse does not seem to cause much trouble).

    So lowering value of C9 until there is no "ringing" in output at pin 1 should make the sync pulse look nicer, I believe. I think a "nicer" sync pulse may give you a little better DISC range. I looked at your video of the "wiper signal" and there is a small ringing "blip" that goes near zero at one end of the DISC pot - it may be making the spike in your DISC sync pulse signal at the very max pot setting -- but probably goes away most of the time, so no big worry.

    3. I would like to see some more graphs of your LF353 output at pin 1 (compared to TX signal on other trace) for different values of C9. What value of C9 makes the ringing completely disappear? Maybe go down to 50pf, 40pf, 30pf, etc.

    Actually, it looked pretty good at 68pf from your graphs, I would choose that value to keep maybe. It would be interesting to see your sync pulse at max and min DISC pot setting with C9 = 68pf.

    4. I think your blob test made the point I wanted to test (even with your genuine Rolex watch involved). I need to think about it some more and maybe do my own tests carefully -- when the blob is really close to the coil maybe that causes some other effect entirely. So requires careful interpretation. But I think it shows that the significant "null signal phase" is not really what we see on our scopes, and so we shouldn't go crazy trying to set a particular value.

    Thanks for all the work making the graphs and videos!

    Cheers,

    -SB

    Comment


    • Originally posted by ivconic View Post

      O.K.
      I already made two G.Sabre's and two S.Sabre's so far.Wanted to know how those are working.
      Also made few coils for those. Already posted some of experiences with coils.
      I want to "establish" one and only good schematic and from now one to make only that.
      Much experiments so far. After dozen different projects i choose Tesoro Golden Sabre to be
      my favorite detector to build. Why? Simply, all real functions that prospector need on
      field G.Sabre already comprehend. Discrimination is so good, it can fully discriminate
      foil, iron.....what man can wish more?
      Depth is great! Maybe i had luck to calculate and make quite proper coil for it, but my
      experiences are so good...much better than some posted previously on this forum. Already
      made few identical coils, just to check if i can make those as standard....It was not lucky
      guess or coincidence, yes i got it for good!
      Also noticed that G.Sabre is for real much better than S.Sabre. Greater depth even 30%.
      Solution with 4024 turns to be more effective than 7660...? Why, i dont know. It seems that
      all stages in device are better synchronized if dependable on main oscillator frequency.
      So i rearranged schematic and cut out "notch" part, so pcb would be as smallest as possiblle.
      I also rechecked schematic and previous pcb...? Except those 2 resistors(4k7) in chopper and
      one missvalued capacitor(15pF) i dont see any other mistake. 4148 diode at LM393 output
      ("Sense" stage) is not reversed??? I think somebody claimed here that it is reversed.
      I never tried to reverse it and see....Made my detectors according to posted pcb and those are
      working good.
      So here is Golden Sabre "light" schematic. I hope it is accurate. Checked few times....
      Next step is to draw small, one-sided pcb for it....Why one-sided? I prefer one-sided pcbs.
      No conditions for metalized holes in pcb's so i mostly do one-sided..
      Also most of my pcb's i draw manually with thin marker.It is much easier to draw single-sided.
      But there is another problem! Huge problem! Mountain problem!
      I do have DXP,Eagle,ExpressPCB,SprintLayout....but still do not have enough paraxis and knowledge
      to draw good pcb with those..Already learned to input schematics.But when comes to pcb i
      really do not have nervs to torture myself with those software. Already tried hundred times and
      at the end, my final pcb's sucks! DXP is very strange! Making its own nets and connections from
      time to time. Eagle is even more stupid. ExpressPCB is simple and stupid, almost like drawing
      manually....To many parameters to input and to be considered. Lost eneormous time even for
      simple designs. At the end final draw is not what i wanted - not perfect.Many lacks.
      That's way i decided to give up of those and let more conversant people to do the job.
      I fully recomend this project to everybody interested.
      No need for "high phylosophy", no need for "high tech" projects.At the end all those are very
      close when comes to performances. This schematic associate all merits which one good detector
      must have...


      Thanks so much
      So the gold light is the final, the accurate ont to work on, and the overview and pcb layout are also correct?
      If so im going to build one, thats if i can get the parts of course.
      I shall take note of your coil designs
      Many thanks again
      Dave

      Comment


      • pcb size

        Hi
        I have ordered all the components, can someone give me the pcb size please? save messing about.
        Many thanks
        Dave

        Comment


        • Originally posted by satdaveuk View Post
          Hi
          I have ordered all the components, can someone give me the pcb size please? save messing about.
          Many thanks
          Dave
          Have you gotten Ivconic's info from this thread? http://www.geotech1.com/forums/showthread.php?t=15710

          You can print out the PCB layout and measure, etc.

          -SB

          Comment


          • Thanks

            Thanks Simon
            I didnt have that information, very greatful.

            Warm regards

            Dave

            Comment


            • Originally posted by fmnotes View Post

              http://imageshack.us/photo/my-images/824/tesoro2.png/
              Hello.
              This psb tgsl it is right?
              It works with these prices of materials that it has?
              version tgsl 3 it is better?
              I request any it knows it helps me.
              I thank
              Hi Fmnotes ,

              The picture you've posted is the Tesoro Golden Sabre 'original ' not the TGSLight
              This version does work however.

              If you want to build the TGSL :

              http://www.geotech1.com/forums/showthread.php?t=15710

              or you can buy one of Silverdogs PCB's : The TGSL EDU
              http://www.geotech1.com/forums/showthread.php?t=17727

              As far as I understand this is almost the same version with some small changes.

              I hope I understood your message well

              kind regards ,

              Dennis the Mennis

              Comment


              • did silver sabre had a pinpoint swith? in original silver sabre micro max has. i was wondering..maybe there is a way to put a pinpoint switch i tgsl? it's wery good to find an object wery fast..i have a original ss micromax pcb without wires( they were wery mest up) and i'm still looking for good original schematic and coil parameters. i heart that bandido is wery similar but has no pinpoint

                anyway..

                best regards

                Comment


                • Originally posted by lunamay View Post
                  did silver sabre had a pinpoint swith? in original silver sabre micro max has. i was wondering..maybe there is a way to put a pinpoint switch i tgsl? it's wery good to find an object wery fast..i have a original ss micromax pcb without wires( they were wery mest up) and i'm still looking for good original schematic and coil parameters. i heart that bandido is wery similar but has no pinpoint

                  anyway..

                  best regards
                  I have a Tesoro Bandido.
                  It has a switch to select Discrim, All Metal or Retune. The All Metal mode is non-motion and used for pinpointing, and the Retune setting restores the threshold in All Metal mode.

                  Comment


                  • Hi DtM!

                    Love those great graphs you get with your USB scope! I have a configuration question: can you configure the graphs to have 10 dots per square instead of 12 (for easy estimate of values)? And can you configure it to show the time scale on the horizontal axis? It would be great also if description of plot can be put on graph so it can be understood without surrounding text. Just some ideas. I hope to get a similar tool some day.
                    Hi Simon ,

                    I will try the configuration of the horizontal axis when my laptop is back from the ICT department again ...
                    The time scale was ( in yellow , see my other pictures ) printed under the grid untill I had a software update for my USB scope due to problems with external triggering , got this problem back ...
                    These were the first pictures I've posted after the update and I didn't notice the missing scale , good observation.

                    Yes , there is a possibility to add text to the bottom of the graphs but it isn't displayed , or at least not when I save it as a GIF file , didn't try the other 'save as' options yet .



                    Ok, now lets look at your data.

                    1. I think your sync pulse looks pretty normal and you should be able to discriminate targets. When I compare these new graphs to habitbraker, they quite similar in shift and location, don't you think so?

                    So my question is: what targets do you use for your discrimination test, and what results do you get again? (My best test target is US Nickel. TGS does not discriminate silver or even copper really).
                    It looks similar to the one of Habitbraker so I must be close ...
                    I didn't spend that much time at the DISC mode in the past because I was a little focused on the ' All Metal ' mode : Why do I get good detection and some time later absolute worse detection . ( In my case really unpredictable noise , some more postings about that later for anyones benefit)
                    And I had a defect in that part of the circuit so it wouldn't work ever ...
                    I will do some more experimenting with different materials.


                    2. I have seen a similar "spike" on my RX null signal at times. I did not consider it might be due to capacitor C9, but that could make sense due to saturation of the LF353 op amp. (The good news, as you said, is that the spike does not seem to hurt the detection. Anything very periodic at the TX frequency should not hurt.)

                    However, the "spikes" on the sync pulse can be definitely related to capacitor C9, because when the LF353 op amp saturates (DISC op amp, pins 1,2,3), it causes a "ringing" output at pin 1 which then can make a messy sync pulse. (Surprisingly, the messy sync pulse does not seem to cause much trouble).

                    So lowering value of C9 until there is no "ringing" in output at pin 1 should make the sync pulse look nicer, I believe. I think a "nicer" sync pulse may give you a little better DISC range. I looked at your video of the "wiper signal" and there is a small ringing "blip" that goes near zero at one end of the DISC pot - it may be making the spike in your DISC sync pulse signal at the very max pot setting -- but probably goes away most of the time, so no big worry.

                    3. I would like to see some more graphs of your LF353 output at pin 1 (compared to TX signal on other trace) for different values of C9. What value of C9 makes the ringing completely disappear? Maybe go down to 50pf, 40pf, 30pf, etc.

                    Actually, it looked pretty good at 68pf from your graphs, I would choose that value to keep maybe. It would be interesting to see your sync pulse at max and min DISC pot setting with C9 = 68pf.
                    I removed C9 and connected an IC socket as a kind of brigde were I can easily place or remove caps .
                    I will post some more graphs with different values for C9


                    4. I think your blob test made the point I wanted to test (even with your genuine Rolex watch involved). I need to think about it some more and maybe do my own tests carefully -- when the blob is really close to the coil maybe that causes some other effect entirely. So requires careful interpretation. But I think it shows that the significant "null signal phase" is not really what we see on our scopes, and so we shouldn't go crazy trying to set a particular value.

                    Thanks for all the work making the graphs and videos!

                    Cheers,

                    -SB
                    Please let me know if want to do some other 'blob' testing.

                    And you're welcome , yes it takes a lot time making all the graphs and videos ...
                    Just like you answering all the posts , I should also thank you Simon . ( and all the others with a helping hand )

                    I hope that the graphs and videos can contribute to anyone having problems or trying to troubleshoot and don't know what to expect , just like me at some points.

                    I hope also to bundle someday all info but that is a lot of work

                    Click image for larger version

Name:	dummies front2.JPG
Views:	1
Size:	120.2 KB
ID:	328666

                    kind regards ,

                    Dennis the Mennis

                    Comment


                    • Originally posted by Dennis the Mennis View Post
                      Hi Simon ,

                      I will try the configuration of the horizontal axis when my laptop is back from the ICT department again ...
                      The time scale was ( in yellow , see my other pictures ) printed under the grid untill I had a software update for my USB scope due to problems with external triggering , got this problem back ...
                      These were the first pictures I've posted after the update and I didn't notice the missing scale , good observation.

                      Yes , there is a possibility to add text to the bottom of the graphs but it isn't displayed , or at least not when I save it as a GIF file , didn't try the other 'save as' options yet .





                      It looks similar to the one of Habitbraker so I must be close ...
                      I didn't spend that much time at the DISC mode in the past because I was a little focused on the ' All Metal ' mode : Why do I get good detection and some time later absolute worse detection . ( In my case really unpredictable noise , some more postings about that later for anyones benefit)
                      And I had a defect in that part of the circuit so it wouldn't work ever ...
                      I will do some more experimenting with different materials.




                      I removed C9 and connected an IC socket as a kind of brigde were I can easily place or remove caps .
                      I will post some more graphs with different values for C9




                      Please let me know if want to do some other 'blob' testing.

                      And you're welcome , yes it takes a lot time making all the graphs and videos ...
                      Just like you answering all the posts , I should also thank you Simon . ( and all the others with a helping hand )

                      I hope that the graphs and videos can contribute to anyone having problems or trying to troubleshoot and don't know what to expect , just like me at some points.

                      I hope also to bundle someday all info but that is a lot of work

                      [ATTACH]15310[/ATTACH]

                      kind regards ,

                      Dennis the Mennis
                      All good... we'll wait for more posts with your findings using DISC mode (if it really is working) and if different C9 values help DISC mode (usually not big difference, but still useful to know).

                      Your book is good looking anyway! The hard part is a way to answer all the questions that get asked about the TGSL!

                      Cheers,

                      -SB

                      Comment


                      • Originally posted by Dennis the Mennis View Post
                        Hi Simon ,

                        I will try the configuration of the horizontal axis when my laptop is back from the ICT department again ...
                        The time scale was ( in yellow , see my other pictures ) printed under the grid untill I had a software update for my USB scope due to problems with external triggering , got this problem back ...
                        These were the first pictures I've posted after the update and I didn't notice the missing scale , good observation.

                        Yes , there is a possibility to add text to the bottom of the graphs but it isn't displayed , or at least not when I save it as a GIF file , didn't try the other 'save as' options yet .





                        It looks similar to the one of Habitbraker so I must be close ...
                        I didn't spend that much time at the DISC mode in the past because I was a little focused on the ' All Metal ' mode : Why do I get good detection and some time later absolute worse detection . ( In my case really unpredictable noise , some more postings about that later for anyones benefit)
                        And I had a defect in that part of the circuit so it wouldn't work ever ...
                        I will do some more experimenting with different materials.




                        I removed C9 and connected an IC socket as a kind of brigde were I can easily place or remove caps .
                        I will post some more graphs with different values for C9




                        Please let me know if want to do some other 'blob' testing.

                        And you're welcome , yes it takes a lot time making all the graphs and videos ...
                        Just like you answering all the posts , I should also thank you Simon . ( and all the others with a helping hand )

                        I hope that the graphs and videos can contribute to anyone having problems or trying to troubleshoot and don't know what to expect , just like me at some points.

                        I hope also to bundle someday all info but that is a lot of work

                        [ATTACH]15310[/ATTACH]

                        kind regards ,

                        Dennis the Mennis
                        Dennis, I am putting together documentation and will have "something" soon! I now have a way to put together a pdf document so I am making progress .

                        Once I complete a rough draft I will post it here for revision. Just one question for everyone: Do I have permission to collect some of the graphs and diagrams already posted??

                        Stay tuned!!

                        Don

                        Comment


                        • Originally posted by dfbowers View Post
                          Dennis, I am putting together documentation and will have "something" soon! I now have a way to put together a pdf document so I am making progress .

                          Once I complete a rough draft I will post it here for revision. Just one question for everyone: Do I have permission to collect some of the graphs and diagrams already posted??

                          Stay tuned!!

                          Don
                          Anything I posted is ok to use. I'll bet if a little credit is given no one would object.

                          -SB

                          Comment


                          • Originally posted by dfbowers View Post
                            Dennis, I am putting together documentation and will have "something" soon! I now have a way to put together a pdf document so I am making progress .

                            Once I complete a rough draft I will post it here for revision. Just one question for everyone: Do I have permission to collect some of the graphs and diagrams already posted??

                            Stay tuned!!

                            Don
                            Hi Don ,

                            Please feel free to use anything you want including the videos , I'm not intending to remove them ever .

                            If you want send me the final schema / diagram Simon (?) ever made for the TGSL with the points marked from which you want a graph or video or both even in rest or with target signal !
                            Just like the 'TGScompare' document.

                            Can't give any guarantee in time but I will make them for you .

                            Wanted to do that for my little 'TGS for Dummies" project but crashed on some places so took more time as expected , was busy to convert the pcb layouts and schematic of the TGS to the TGSL numbering...( must be out of my mind , this costs lots of lots of time )

                            schematic 190 Kb TIFF.TIF

                            allthough I have the TGS , it is ( I think) almost similar to the TGSL .

                            Let me know,

                            kind regards ,


                            Dennis the Mennis

                            Comment


                            • Originally posted by Dennis the Mennis View Post
                              Hi Don ,

                              Please feel free to use anything you want including the videos , I'm not intending to remove them ever .

                              If you want send me the final schema / diagram Simon (?) ever made for the TGSL with the points marked from which you want a graph or video or both even in rest or with target signal !
                              Just like the 'TGScompare' document.

                              Can't give any guarantee in time but I will make them for you .

                              Wanted to do that for my little 'TGS for Dummies" project but crashed on some places so took more time as expected , was busy to convert the pcb layouts and schematic of the TGS to the TGSL numbering...( must be out of my mind , this costs lots of lots of time )

                              [ATTACH]15322[/ATTACH]

                              allthough I have the TGS , it is ( I think) almost similar to the TGSL .

                              Let me know,

                              kind regards ,


                              Dennis the Mennis
                              Hi Dtm:

                              I forgot you made TGS, not TGSL -- is that correct? Or do you have both?

                              For TGS, that changes my understanding of some of your issues. For example, it probably is a little more important to have the 100K DISC pot instead of 10K, because there is another 10K pot in parallel. Also, C9 probably not a problem because TX wave will be smooth and smaller voltage. Also, you would expect less air depth because smaller TX signal.

                              Next step is to get results of your DISC mode detection - what depth, what coins used? Also, which circuit (TGS or TGSL)?!

                              TGSL for dummies project is ambitious, and you end up teaching yourself how it all works! Some people may want permissions for exact design for example PCB layouts I would think. I hope someday I can make a significantly modified design and my own layout of some MD and publish a book/manual also. I use lulu.com for my publishing projects.

                              Cheers,

                              -SB

                              Comment


                              • TGS proteus
                                Attached Files

                                Comment

                                Working...
                                X
